| Activité |
Cyclisme |
| Amortisseur Arrière |
Fox Float DPS Factory Kashima EVOL LV, 205×57.5mm. Settings: Compression 3 positions lever, low speed compression, low-speed rebound, air preload. Trunnion top mount, 30x8mm bottom bushings |
| Bidex Code |
101020 |
| Cadre |
Raze 29 Stealth Air full Carbon, Zero Suspension System, 130mm travel, Forward Geometry, Carbon Monoblock upper link, Boost 12x148mm rear axle, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, HHG internal cable routing, Enduro MAX sealed bearings, shock mudguard, ISCG 05, custom frame protectors. MIND System (EU only) |
| Cassette |
Sram XG-1275, 10-52T, 12s |
| Catégorie principale |
Hardgoods |
| Chaine |
Sram GX Eagle, 12s, Powerlock |
| Dérailleur arrière |
Sram X01 Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1 |
| FEDAS Code |
160027 |
| Fourche |
Fox 36 29 Float GRIP2 Factory Kashima, 150mm, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: high and low-speed compression, high and low-speed rebound, air preload |
| Freins |
Sram G2 RS, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pads |
| GTIN/EAN : |
8435392858069 |
| Groupe principal de marchandises |
Mountain bikes |
| Guidon |
Onoff Krypton Carbon 1.0, rise: 25mm, width: 800mm, 9° backsweep, 5° upsweep, 31.8mm barbore |
| Jantes |
Mavic CrossMax XL S, 29 Boost 30mm internal width, hookless, tubeless ready, 24 spokes |
| Jeu de Direction |
Acros custom for 1-1/2” head tube, angular contact bearings 40x52x7, Internal cable routing |
| Kreditorenartikelnummer |
010.23089 |
| Leviers de Vitesse |
Sram Trigger GX Eagle, 12s, X-Actuation 1:1 |
| Marque |
Mondraker |
| Masternummer |
7002301180 |
